The Air Sizer 200 is ideal for sieving very fine dry particles, which require efficient dispersion and desagglomeration via air jet technology (e.g. electrostatic material).
It is also the perfect instrument to quickly provide a sieve cut of powdered materials.
Sieving Machine AIR SIZER 200 Product Advantages
- Advanced air jet technology for fine particles, usable for dry material 20 µm upwards
- Adjustable nozzle speed, 5 - 55 rpm
- Extremely efficient & fast sieving times
- Sieving action keeps apertures clear
- Air flow fluidises and helps to separate sample
- Ideal for electrostatic materials
- Cyclone & industrial vacuum available as accessories
- Maintenance free
Sieving Machine AIR SIZER 200 Technical Data
| Range: | 20 µm - 4 mm |
|---|---|
| Drive / sieving motion: | dispersion by air jet |
| Max. number of sieves: | 1 |
| Max. mass of sieve stack: | a standard sieve |
| Speed: | 5 - 55 rpm (nozzle speed) |
| Time display: | digital, 0:10-99:50 min |
| Vacuum: | 20 - 99 mbar |
| Suitable for dry sieving: | yes |
| Suitable for wet sieving: | no |
| Max. height of sieve stack: | 1 sieve |
| Accessories: | Cyclone / industrial vacuum |
| Model: | benchtop |
| Protection code: | IP 40 |
| Electrical supply: | 100 - 240 V , 50/60Hz |
| Power connection: | 1 - phase |
| W x H x D: | 450 x 235 x 435 mm |
| Net weight: | ~ 16 kg |
| Standards: | CE |
